Standards • IEEE 802.3, 802.3u, 802.3ab, 802.3ae, 802.3aq, 802.3z compliance • Support Half/Full-Duplex operations • IEEE 802.3x Flow Control and back pressure support • SFF-8431 compliant transceiver support Supported SFP Transceivers • DEM-310GT (1000Base-LX, Single-mode, 10km) • DEM-311GT (1000ase-SX, Mutli-mode, 550m) • DEM-312GT2 (1000Base-SX, Multi-mode, 2km) • DEM-314GT (1000BASE-LHX, Single-mode, 50km) • DEM-315GT (1000BASE-ZX, Single-mode, 80km) • DEM-330T/R (WDM transceiver, Single-Mode 10km) • DEM-331T/R (WDM transceiver, Single-Mode 40km) • DEM-210 (100Base-FX, Single-mode, 15km) • DEM-211 (100Base-FX, Multi-mode, 2km) • DEM-220T/R (100Base-BX, Single-Mode, 20km) • DGS-712 (1000BASE-T Copper SFP Transceiver) 10/100/1000M ports comply with following standards • IEEE 802.3 compliance • IEEE 802.3u compliance • IEEE 802.3ab compliance • Support Half/Full-Duplex operations • IEEE 802.3x Flow Control support for Full-Duplex mode SFP+ ports comply with following standards • IEEE 802.3ae compliance • IEEE 802.3aq compliance Supported SFP+ Transceivers • DEM-431XT: 10GBASE-SR SFP+ Transceiver (w/o DDM), 80m: OM1 & OM2 MMF, 300m: OM3 MMF • DEM-431XT-DD: 10GBASE-SR SFP+ Transceiver (with DDM), 80m: OM1 & OM2 MMF, 300m: OM3 MMF • DEM-432XT: 10GBASE-LR SFP+ Transceiver (w/o DDM), 10km • DEM-432XT-DD: 10GBASE-LR SFP+ Transceiver (with DDM), 10km • DEM-433XT: 10GBASE-ER SFP+ Transceiver (w/o DDM), 40km • DEM-433XT-DD: 10GBASE-ER SFP+ Transceiver (with DDM), 40km • DEM-434XT: 10GBASE-ZR, 80km (w/o DDM) • DEM-435XT: 10GBASE-LRM SFP+ Transceiver (w/o DDM), 220m: OM1 & OM2 MMF, 300m: OM3 MMF • DEM-435XT-DD: 10GBASE-LRM SFP+ Transceiver (with DDM), 220m: OM1 & OM2 MMF, 300m: OM3 MMF • DEM-436XT-BXU: 10GBASE-LR BiDi SFP+ Transceiver (w/o DDM), 20km, TX: 1270nm, RX: 1330nm • DEM-436XT-BXD: 10GBASE-LR BiDi SFP+ Transceiver (w/o DDM), 20km, TX: 1330nm, RX: 1270nm • DEM-310GT (1000Base-LX, Single-mode, 10km) • DEM-311GT (1000ase-SX, Multi-mode, 550m) • DEM-312GT2 (1000Base-SX, Multi-mode, 2km) • DEM-314GT (1000BASE-LHX, Single-mode, 50km) • DEM-315GT (1000BASE-ZX, Single-mode, 80km) • DEM-330T/R (WDM transceiver, Single-Mode, 10km) • DEM-331T/R (WDM transceiver, Single-Mode, 40km) Supported SFP+ Direct Attached Cables • DEM-CB100S: 10G, 1m • DEM-CB300S: 10G, 3m • DEM-CB700S: 10G, 7m Switching Fabric • 88Gbps Data Transfer Rates • 268.44Mpps CPU • 400MHz Memory • 1G DDR2 RAM Flash memory: • Prom 4MB, Runtime 128MB Fiziksel Özellikler Weight • 3.33Kg Power Consumption • 137.67W Heat Dissipation • 469.75BTU/hr Operating temperature • 0° to 50°C Storage temperature • -40° to 70°C Humidity • Operating: 10% to 90% RH (non-condensing) • Storage: 5% to 90% RH (non-condensing)
