DEM-310GT
1000Base-LX Single-Mode SFP transceiver (up to 10 km)
Tanımlama
The DEM-310GT Gigabit SFP fiber transceiver is external transceiver designed for insertion in SFP (Small Form-Factor Pluggable) slot of network device for transmission and reception of data signals on the fiber cables. This transceiver provides high-speed and reliable long-distance (up to 10 km) data transfer.
The DEM-310GT transceiver uses standard duplex LC connector for fiber cable connection. It conforms to industry standards and is interoperable with D-Link Gigabit switches. All D-Link transceivers are hot-pluggable. Hot-swap capability allows network administrators to plug or unplug it from the SFP slot without having to turn off the power of the connected device.
Genel Özellikler
|
General features
|
|
|
Standard
|
• IEEE 802.3z 1000Base-LX
• IEEE 802.3ah
|
|
Wavelength
|
• 1310 nm
|
|
Data Rate
|
• 1.25 Gbps
|
|
Connector
|
• Duplex LC
|
|
Fiber Type
|
• 9/125 um Single-mode Fiber
|
|
Maximum Fiber Cable Length
|
• 10 km
|
|
Transmit Power Range
|
• -3 to -9 dBm
|
|
Receive Power Range
|
• -3 to -22 dBm
|
|
Sensitivity
|
• -22 dBm
|
|
Supported Features
|
• Hot swap
• MSA compliant
• RoHS compliant
|
|
Physical Parameters
|
|
|
Power Support
|
• 3.3 V
|
|
Supply Current
|
• 220 mA
|
|
Temperature
|
• Operating: 0° to 70°C
• Storage: -40° to 85°C
|
|
Humidity
|
• Operating: 0% to 85%
• Storage: 0% to 85%
|
|
Dimensions
|
• 55.4 mm x 13.7 mm x 8.5 mm
|
Çözümler
Sipariş Bilgisi
DEM-310GT/A1A 1000Base-LX Single-Mode SFP transceiver (up to 10 km)
Görseller
DEM-310GT/A1
