DCS-4602EV
Vigilance 2 Megapixel H.265 Outdoor Dome Camera
Tanımlama
The D-Link DCS-4602EV Vigilance 2 Megapixel H.265 Outdoor Dome Camera is a high-definition professional surveillance solution suitable for small, medium, and large enterprises. The camera uses a high-sensitivity 1/2.7 2 megapixel progressive scan CMOS sensor with onboard WDR image enhancement to deliver truly superior quality video in all conditions. The all-in-one rugged design makes this camera extremely reliable and ideal for deployment in surveillance applications without the need for additional accessories.
High-Quality Streaming & Recording
To maximize bandwidth efficiency and improve image quality, the DCS-4602EV provides real-time video compression using the H.265, H.264, and MJPEG codecs, and supports three separate profiles for simultaneous video streaming and recording. Video resolutions of up to 1920 x 1080 provide clear details, and noise reduction and support for simultaneous video streams improves quality in case forensic work is required for evidence. Additional support for motion detection, event management features, and ePTZ allow for implementation in a wide variety of surveillance applications such as monitoring public areas to detect incidents and to coordinate responses, enforcing access control to restricted areas, deterring criminal activity, or monitoring inventory.
Versatile Monitoring in All Environments
The DCS-4602EV’s features WDR image enhancement to deliver improved image quality in conditions with uneven or difficult lighting, so you can identify subjects that are backlit or in brightly-lit areas. In low-light situations, the IR-cut filter automatically slides out of the way to use all available light. The DCS-4602EV also has built-in IR LED illuminators with a 20-meter range, allowing the camera to keep watch even in complete darkness. IP66 certification ensures the camera is completely protected from dust and water in any environment and IK10 certified vandal-proof housing makes sure it keeps recording even when intruders attempt to sabotage the camera. These features work together to give you a reliable surveillance camera capable of monitoring indoors or outdoors 24/7.
Robust Management Software
The DCS-4602EV Vigilance 2 Megapixel H.265 Outdoor Dome Camera includes D-ViewCam, a complete surveillance software package that enables you to view, manage, and record from up to 32 cameras on a single computer in a central location. Recordings and e-mail alerts can be triggered upon
motion detection or by digital input devices. This feature automatically keeps a record of any unusual activity and notifies administrators when no one is around to monitor on-site.
Flexible Connectivity
The DCS-4602EV has built-in 802.3af-compliant PoE support that simplifies installation by providing power and networking connectivity over a single standard network cable: This feature can speed along installation by reducing the need to lay extra electrical wiring and install outlets in the location since a motion detection or by digital input devices. This feature automatically keeps power supply is not required.
Genel Özellikler
Hardware Profile
• 1/2.7 2 Megapixel progressive CMOS sensor
• 20 meter IR illumination distance
• Minimum illumination:
- 0.1 lux / F2.0 (color)
- 0.05 lux /F2.0 (B/W)
- 0 lux / F2.0 (IR-LED on)
• Built-in Infrared-Cut Removable (ICR) Filter module
• 10x digital zoom
• Minimum object distance 0.5 m
• Focal length: 2.8 mm
• Aperture: F2.0
• Angle of view:
- (H) 120В°
- (V) 66В°
- (D) 140В°
• Adjustment angle (non-motorized):
- Vertical: 30~90В°
- Horizontal: -120~120В°
Camera Housing
• IP66 compliant weatherproof housing
• IK10 compliant vandalproof housing
Image Features
• Configurable image size, quality, frame rate, and bit rate
• Configurable motion detection windows
• Configurable privacy mask zones
• Configurable shutter speed, brightness, saturation, contrast, sharpness and 3D filter
• Auto White Balance (AWB)
• Auto Gain Control (AGC)
• Wide Dynamic Range (WDR)
• Time stamp and text overlays
Video Compression
• Simultaneous H.265/H.264/MJPEG format compression
• H.265/H.264/MJPEG multicast streaming
• JPEG for still images
Video Resolutions
• 16:9 - 1920 x 1080, 1280 x 720, 800 x 448, 640 x 360 up to 30 fps
• 4:3 - 1600 x 1200, 1440 x 1080, 1280 x 960, 800 x 600, 640 x 480 up to 30 fps
External Device Interface
• 10/100 Base-TX Fast Ethernet port
• Supports 802.3af PoE Class 3
• microSD/SDHC/SDXC card slot*
Network Protocols
• IPv6
• IPv4
• ARP
• TCP/IP
• UDP
• ICMP
• DHCP client
• NTP client (D-Link)
• DNS client
• DDNS client (D-Link)
• SMTP client
• FTP client
• HTTP/HTTPS
• Samba client
• PPPoE
• UPnP port forwarding
• RTP/RTSP/RTCP
• IP filtering
• Multicast
• CoS
• QoS/DSCP
• SNMP
• ONVIF compliant
Security
• Administrator and user group protection
• Password authentication
• HTTP and RTSP authentication
Event Management
• Motion detection
• Tamper detection
• Event notification and uploading of snapshots/video clips via e-mail or FTP
• Supports multiple SMTP and FTP servers
• Multiple event notifications
• Multiple recording methods for easy backup
Remote Management
• Take snapshots/video clips and save to local hard drive via web browser
• Configuration accessible via web browser
System Requirements for Web Interface
• Operating System: Microsoft Windows 7 / 8 / 10
• Browser: Internet Explorer, Firefox, Chrome
D-ViewCam Software Functions
• Supports all management functions provided in web interface
• Viewing of up to 32 cameras on one screen
• Remote management/control of up to 32 cameras
• Scheduled motion triggered, or manual recording options
D-ViewCam System Requirements
• Operating System:
- 32-bit: Windows 8 / 7 (SP1)
- 64-bit: Windows 10 / 8 / 7 (SP1) / Server 2012 / Server 2008 R2
• Web Browser: Internet Explorer 7 or higher
• Protocol: Standard TCP/IP
Physical Parameters
Weight
• 365 grams В± 5%
Dimensions
• Diameter: 99 mm
• Height: 64.7 mm
Power
• Input: 100 to 240 V AC, 50/60 Hz
• Output: 12 V DC 1.5 A
Power Consumption
• 6.6 W В± 5% (PoE)
Temperature
• Operating: -30В° to 50В°C
• Storage: -20В° to 70В°C
Humidity
• Operating: 20 to 80% non-condensing
• Storage: 5% to 95% non-condensing
Certifications
• CE
• CE LVD
• FCC
• RCM
* Camera is compatible with microSD/SDHC/SDXC cards (128 GB max.) up to v3.01. Camera is not compatible with v4.x cards.
Çözümler
Sipariş Bilgisi
DCS-4602EV/UPA/B1 Vigilance 2 Megapixel H.265 Outdoor Dome Camera
