DUB-2327
USB-C Mini Docking Station with 2xUSB 3.0, USB-C/PD 3.0, HDMI and SD/microSD Card Reader
Tanımlama
The DUB-2327 docking station allows you to enhance the functionality of your laptop or desktop computer equipped with USB Type-C port. USB 3.0 ports allow to connect up to two peripheral USB devices to the DUB-2327, HDMI port1 supporting up to 4K resolution is used for connecting monitor, and dual slot SD card reader allows you to insert SD2 and microSD3 cards into the corresponding slots. USB Type-C port is intended for connecting PD 3.0 charger, allowing to deliver not only data, but also power to your laptop via connected DUB-2327 docking station4. This means you can charge your laptop while also connect additional devices like monitors, SD2 and microSD3 cards, digital and web cameras, card readers, hard drives, mice, keyboards, printers, scanners, and other peripheral devices.
Add Two USB 3.0 Ports to Your Computer
With the DUB-2327 docking station, you can conveniently add two USB 3.0 ports and connect peripheral devices to your computer. USB 3.0 technology supports data rates of up to 5 Gbps.
Dual Slot SD Card Reader
The DUB-2327 docking station is equipped with the SD and microSD card slots. Use the dual slot card reader to access data on a SD2 and microSD3 card simultaneously.
PD 3.0 Standard
USB Type-C port is intended for connecting PD 3.0 charger, allowing to deliver not only data, but also power to your laptop via connected DUB-2327 docking station4.
Plug-and-Play Support
Simply connect the DUB-2327 to your computer. It’s that easy - no drivers or software installation is required.
1Please make sure that the USB Type-C port of your computer supports DP Alt (DisplayPort Alternate Mode).
2The docking station is compatible with SD/SDHC/SDXC cards.
3The docking station is compatible with microSD/SDHC/SDXC cards.
4Please make sure that the USB Type-C port of your laptop supports PD 3.0.
Genel Özellikler
|
Hardware
|
|
|
Interfaces
|
• One USB Type-C connector
• Two USB 3.0 Type-A ports
• One USB Type-C/PD 3.0 port
• One HDMI 1.4b, HDCP 1.4 port
• SD card slot1
• microSD card slot2
|
|
LEDs
|
• Power (per device)
- Solid green - power is on
|
|
General
|
|
|
Standards
|
• USB 3.0
• USB 2.0
• USB 1.1
|
|
Data rate
|
• Up to 5 Gbps
|
|
Resolution
|
• 4K @ 30 Hz, 1080P @ 120 Hz
|
|
System requirements
|
• Available USB Type-C port
• Windows 7/8/8.1/10, macOS (OS X 10.8 and above)
|
|
Physical Parameters
|
|
|
Dimensions (L x W x H)
|
• 118 x 35 x 13 mm
|
|
Weight
|
• 0.07 kg
|
|
Environmental Conditions
|
|
|
Power input
|
• From computer (USB bus powered)
|
|
Supplied charging voltage/current
|
• 20 V / 3 A (PD 3.0)
|
|
Temperature
|
• Operating: 0 to 45°C
• Storage: -10 to 70°C
|
|
Humidity
|
• Operating: up to 85% non-condensing
• Storage: up to 85% non-condensing
|
|
Package Contents
|
|
|
• DUB-2327 docking station
• Quick Installation Guide
• Warranty documents
|
|
1The docking station is compatible with SD/SDHC/SDXC cards.
2The docking station is compatible with microSD/SDHC/SDXC cards.
Çözümler
Sipariş Bilgisi
|
DUB-2327/A1A
|
USB-C Mini Docking Station with 2xUSB 3.0, USB-C/PD 3.0, HDMI and SD/microSD Card Reader
|
